We’re glad you found us! If you are looking for the very best in selection and quality, them look nor further – we pride ourselves in offering the very best in selection and quality. We are confident that we can provide you with a trailer that will exceed you expectations in every way, so have a look below at what we offer and let’s get started!
Standard specifications
These are features offered on all of our trailers.
5 Wide
- 5’ Interior height
- 24×57 Rv door
- 4-way Bargman plug
- 3500lb axle (Sure trac) drop leaf spring
- 2×3 steel tube rails in frame
6/7 Wide
- 6’3 Interior height
- 6 wides single axle use 2×3 main rails
- Tandem axles use 2×4 main rails
- 4-way bargman plug for single axle 2” coupler
- 7-way plug for tandem axle/ 2” 5/16 coupler
- 32×68 RV side door
- 3500lb axle (Sure trac) drop leaf spring
- 16” OC walls and floor crossmembers
- 24” OC roof
- 1x 1 ½ steel tube in walls and ceiling
- 3/8 plywood
- ¾ plywood decking
- LED lights
- Chrome center lug cover
- V nose with ATP vertical trim
- 024 metal ( blk wht red silver pewter charcoal)
- 24” ATP stoneguard on v nose
- Galvalume roof
- Z tech undercoated frame
- Plywood painted underneath
- Radial tires
- 2000lb tongue jack
- Choice of ramp door or double barn door
- Choice of roof vent or side vent
8.5 Wide
- 6’6 Interior height; 6” “Ibeam; 4 D rings
- 36×75 RV door
- Beavertail with ramp
- 24ft and above have 5200lb axle
- 28ft has double 6” Ibeam frame
- 26ft and above have amber turn signal over wheel well; DOT TAPE
- 30ft and above have 8” Ibeam frame and triple tube tongue
- 34ft and above have triple 5200lb axle
Options
We have a wide variety of sizes, materials, and options to choose from. Have a look below at what we can do for you and let your imagination run wild!
Size
- 5x6sa $1750
- 5x8sa $1850
- 5x10sa $1950
- 6x8sa $2050
- 6x10sa $2150
- 6x10ta $2750
- 6x12sa $2300
- 6x12ta $2900
- 6x14sa $2450
- 6x14ta $3050
- 7x10sa $2400
- 7x10ta $2900
- 7x12sa $2500
- 7x12ta $3100
- 7x14sa $2825
- 7x14ta $3300
- 7x16ta $3450
- 7x18ta $3850
- 7x20ta $3950
- 8.5x12ta $3645
- 8.5x14ta $3755
- 8.5x16ta $3920
- 8.5x18ta $4085
- 8.5x20ta $4250
- 8.5x20ta3 $4650
- 8.5x22ta $4360
- 8.5x24ta $4455
- 8.5x24ta3 $4855
- 8.5x26ta3 $5075
- 8.5x28ta $5185
- 8.5x30ta3 $6000
- 8.5x32ta3 $6285
Structure
- 3” extra height (only on 6&7) $6plf
- 6” extra height $12plf
- 12” extra height $24plf
- 18” extra height $36plf Requires HD Ramp
- 12” OC floor crossmembers (7&8.5) $13plf
- 12” OC floor crossmembers (6) $12plf
- 16” OC roof bows (over 24”) $9plf
- 12” OC wall members $18plf
- 6” extended triple tube tongue (54”) $100
- 12” extended triple tube tongue (60”) $110
- 18” extended triple tube tongue (66”) $150
- Spare Tire Mount – on tongue $100
- Porch/Hybrid (-ft enclosed/-ft open) with or without roof 1x 1 ½ steel tube railing around porch with removable rear section and swing out Gate –8.5 &7 only $600
- Walk-on roof (12” OC roof bows on 8.5 16” OC on 6 &7) , 3/8” plywood on _ top of roof bow and 1pc aluminum roof $40plf
Interior
- Pressure treated plywood flooring $15plf
- 2×6” pressure treated decking for porch floors $45plf
- Upgrade to ½” plywood walls over 3/8 $15plf
- ¾” plywood walls over std 3/8” $15plf
- Double ¾” plywood floor $15plf
- RTP floor covering $45plf
- ATP floor covering $45plf
- RTP or ATP on ramp and flap $225
- Black & White floor covering $45plf
- Black & White on ramp and flap $225
- White vinyl walls $30plf
- White vinyl ceiling $20plf
- Metal on ceiling with luan backing $45plf
- Metal walls $45plf
- Insulate walls $15plf
- Insulate ceiling $10plf
- Luan ceiling liner $10plf
- Wood shelf in v nose 6 or 7 wide $110
- Wood shelf in v nose 8.5 wide $160
- Base cabinet in vnose $700
- Base & over head cabinet $1200
- Pull out drawer $150
- Interior generator box 36×40 plywood w 36×36 generator door $550
Vents
- Non-powered roof vent $55
- Powered roof vent $75
- Plastic flow-thru side wall vents (pair) $40
- 2-way aluminum sidewall vents (pair) $125
- Brace for A/C $45
- Wire and brace A/C $55
- 13500 BTU A/C installed $1200
- Max flow cover for ceiling $150
Doors & Ramps
- Full width piano hinge for flap $15
- ATP transition flap between ramp and trailer $150
- HD ramp (adds 100lb to std ramp capacity) required for over 12” extra height $150
- Super Duty ramp (adds 2000lb to std ramp capacity) required for over 24” extra height $300
- back latch for door (ea) $7
- 24” RV side door for 5 wide $220
- Add bar lock to any RV door $60
- Upgrade from 32” to 36” RV door $110
- Upgrade from 36” to 48” RV door $160
- Extra 36×75” RV door $285
- Upgrade to RV side door w/screen door $425
- Additional RV side door w/screen door $525
- 12×12” gas access door $125
- 52×48” escape door $295
- 3×3 access door or generator door $235
- 30”x30” RV style window (vertical or horizontal slide please specify) $265
- 30×15” RV style window $225
Tiedowns, Stabilizers, & Other Tongue related options
- Pair of fold-down stabilizer jacks $65
- Scissor jacks (pair) $150
- Wall D-rings (ea) $15
- Floor D-rings (ea) $20
- E-track in wall $15plf
- E-track in floor with steel backer $16plf
- Electrical jack $300
- Bogey wheels under rear (pair) $155
- ATP cover over tongue $150
Axles
- HoldExtra 3500lb axle $750
- Extra 5200lb axle $950
- Extra 7000lb axle $1250
- Upgrade 3500lb to 5200lb axle (single axle) $325
- Upgrade 3500lb to 5200lb axle 6w requires6” Ibeam upgrade also $375per axle
- Upgrade 3500lb drop axle to Electric Brake $225
Wheels & Tires
- Spare 15/205 radial tire $120
- Spare 15/225 radial tire $150
- Spare 16/235 radial tire $190
- Spare 15/205 radial tire w/ Mag wheel $180
- Spare 15/225 radial tire w/ Mag wheel $210
- Spare 16/235 radial tire w/ Mag Wheel $250
- Upgrade 15/205 to Mag wheel $185
- Upgrade 15/225 to Mag wheel $205
- Upgrade 16/235 to Mag wheel $255
- Spare tire mount (interior) $60
- Spare tire mount (exterior) extended tongue required $60
- Spare tire mount on tongue mast (extended tongue required) $100
- Spare tire cabinet -14” deep (1-36”x36” door to: interior or exterior) $345
Exterior
- 024 standard color: white, black, charcoal, silver, pewter, red
- 030 metal: yellow, orange, beige, indigo blue, brandy wine, emerald green $15plf
- Special order metal 030: electric green and deep blue $27plf
- 12” ATP or Anodized bottom trim sides, rear, bottom of door $9plf
- 24” ATP or Anodized bottom trim sides, rear, bottom of door $19plf
- Black 12” ATP bottom trim sides and rear $15plf
- Black 24” ATP bottom trim sides and rear $19plf
- Semi-screwless metal exterior (screws in sems only) 030 required $15plf
- Black out pkg 20ft and over $600 under 20ft $500
- Anodized /ATP front corner on 6 and 7 $70
- Anodized /ATP rear corners on6 and 7 $70
- Upgrade ATP single axle fender (pair) $50
- Upgrade ATP TA axle fender (pair) $90
- 2 tone w/anodized strip $350
- 2 tone w/out anodized strip $300
- 1 pc Aluminum roof $17plf
- Walk on roof 12” OC roof bows on8.5 16” OC on6 &7, 3/8 plywood on__ top of roof bows and 1pc aluminum roof $40plf
- ATP generator box on tongue (flat front required) $500
- Premium slide out tray in generator box (ordered) $450
- Aluminum ladder rack ea $210
- Aluminum ladder to roof $450
- App pkg SA $120 TA $195 Triple $270 ATP fender, 12” ATP sides& rear, slant cut stoneguard
Electrical Packages
- 30 AMP PKG $475 6 -space panel box, 30 amp main breaker, 30 amp lifeline, cable hatch, 2 110v receptacles, 2 4’ fluorescent light with 1 switch
- 50 AMP PKG $590 8-space panel box, 50 amp main breaker, 50 amp lifeline, cable hatch, 2 110v receptables, 2 4’ fluorescent light with 1 switch
- 100 AMP PKG $625 10-space panel, 100 amp main breaker, 50 amp lifeline, cable hatch 2 110v receptables 2 4’ fluorescent light with 1 switch 5 20 amp breakers
- GFI recept for exterior $90
- Wire for exterior light w/stitch no light include $55
- 3AMP motor base $75
- 50AMPmotor base $110
- Extra 110v recept $50
- 500w Recessed Quartz light ea $220
- Upgrade to 10/2 wires $90
